NB-500DTY Multi-frequency Ultrasonic Cleaning Machine
NB-500DTY Multi-frequency Ultrasonic Cleaning Machine

NB-500DTY Multi-frequency Ultrasonic Cleaning Machine




product details

NB-500DTY  Multi-frequency Ultrasonic Cleaning Machine:



The design of the equipment is based on the users' requirement of ultrasonic power, ultrasonic frequency, ultrasonic time. Having the following functions: cleaning, decentralized extraction, nano-preparation, chemical reactions, degassing, defoaming, emulsification, mixing etc. It has broken the traditional cleaning pattern by the single-frequency washing machine. Through multi-frequency conversion 25KHz, 28KHz, 40KHz and 59KHz, the whole process of perfunctory washing, washing in clean water, precision cleaning and rinse is complete within a single machine, giving a thorough cleaning to the washing objects with the result that no fine and stubborn dirt is left anywhere.



● Background light LCD screen

● Microcomputer memory setting parameters

● The ultrasonic working time set up independently: (0-99 minutes adjustable)

● Multi-frequency conversion: 25KHz, 28KHz, 40KHz, 59KHz

● Display woking countdown time

● Display actual temperature of the cleaning tank

● Temperature setting range: Ambient Temperature -- 80 ℃

● Timing range: 0-999 minutes adjustable

● Equipped with a special stainless steel basket, reduction sound cover

● The shell and cover are made of stainless steel

● The equipment controlled by single-chip controller

● With Drainage function




Model Inner tank Volume Frequency Power Heating power Rack Drainage
L/W/H  ( mm) L KHZ W W
NB-300DTY 300×240×150 10 25 300 320
NB-400DTY 300×240×200 15 25 400 320
NB-500DTY 500×300×150 22.5 28 500 600
NB-600DTY 500×300×200 30 40 600 3000
NB-1000DTY 600×300×300 54 59 1000 4000
NB-1200DTY 600×400×300 70 59 1200 4000
