15t/24h Seawater flake ice machine
15t/24h Seawater flake ice machine

15t/24h Seawater flake ice machine

Brand:NANBEI

Model:ZNPB15J-HS/FA

Application:

product details

 Application Field:

●Aquatic product processing

●Offshore fishing vessel

●Fish cooling and packing

●Ports and terminals ice plant
●Coastal island fresh seafood
●Shipping Logistics preservation
●Fresh preservation and cooling field application



Sea Water Flake Ice Machine Features:

Reasonable Design

NANBEI sea water ice machine is with integrated structure design, and all our equipments are designed on the basis of modules, so the spot maintenance is simple by removing the old parts and install the new ones. Furthermore we always give consideration to how to conveniently move the ice machine to other places.

High Stability

NANBEI always aims at researching and manufacturing high efficient and energy-saving refrigeration system; the flake ice machine adopted international ice machine processing technology and experience, it can produce quality flake ice and constantly operate over 20,000 hours without failure.

Corrosion-resistance

NANBEI sea water flake ice machine adopted corrosion-resistant material, such as pure aluminium alloy or stainless steel SUS316, its life time is over 18 years.

Water & Energy Saving

NANBEI flake ice machine recycles all unfrozen water back to the ice machine so as to ensure all water is converted to ice and save water resources; Our unique evaporator processing technology makes it better heat exchange efficiency and saves more energy, besides our patented internally-scraping ice scraper can help reduce energy consumption.



Sea Water Flake Ice Machine Technical Specifications

Model

Capacity(tons/24h)

Refrigeration Capacity (kW)

Total Power

Weight

Dimension (L*W*H)(mm)

ZNPB1.0J-HS/FA

1

6.37

5.2 kW

230 kg

1400*910*1078

ZNPB2.0J-HS/FA

2

10.8

7.9 kW

320 kg

1500*910*1198

ZNPB3.0J-HS/FA

3

17.55

12.8 kW

650 kg

1600*1200*1500

ZNPB4.0J-HS/FA

4

22.5

16.3 kW

700 kg

1800*1200*1500

ZNPB5.0J-HS/FA

5

25.5

18.4 kW

850 kg

2000*1500*1800

ZNPB6.0J-HS/FA

6

30.1

21.6 kW

1000 kg

2200*1500*1800

ZNPB8.0J-HS/FA

8

50.7

40.3 kW

1200 kg

2500*1700*2000

ZNPB10J-HS/FA

10

58.1

45.8 kW

1400 kg

2300*1700*2000

ZNPB15J-HS/FA

15

96.4

68.97 kW

3200 kg

3400*2000*2300



Note:

1) Standard Supply Power: 380V/50Hz/3Phase. Ice machine can be customized upon non-standard power.

2) Cooling System: Water Cooling System

3) Supply Water: Sea Water

4) Refrigerant: R22/R404a

5) Ice Thickness: 1.5~2mm

6) Standard Working Condition: Ambient temperature: 25; Water supply temperature: 16; Evaporation temperature: -30.

7) Applicable Working Condition: Ambient temperature: 5~40℃;  Water supply temperature: 0~40.

8) Specifications are subject to change without notice.
