TM-XA24D Fully Automatic Microcomputer Table Top Steam Sterilizer
TM-XA24D Fully Automatic Microcomputer Table Top Steam Sterilizer

TM-XA24D Fully Automatic Microcomputer Table Top Steam Sterilizer

Brand:NANBEI

Model:TM-XA24D

Application:It is ideal equipment for clinics, scientific research institutes and other organizations to sterilizer surgical instruments, fabrics, glasses, culture media etc.

product details

Fully automatic microcomputer table top steam sterilizer


Characteristics:

1.For 4~6 minutes rapidly sterilizing.

2.Digital display of working status,touch type key.

3.With 3 fixed cycles of water adding,temperature rising,sterilizing,drying steam discharging controlled automatically.

4.Steam-water inner circulation system:no steam discharge,and the environment for sterilizing will be clean and dry.

5.Exhaust the cool air automatically.

6.Safe protection of water lacking.

7.Door safety lock system.

8.With three stainless steel sterilizing plates.

9.The chamber of the sterilizer is made of stainless steel.

10.Automatically shut off with beep reminding after sterilization.

11.With drying function.


Technical data:

 MODEL TECHNICAL DATA
TM-XA20D
TM-XA24D
Sterilizing chamber volume
20L(φ250×420 mm)
24L(φ250×520 mm)
Maximum working pressure
0.22Mpa
Maximum working temperature
134℃
Adjustment of temperature
105-134℃
Timer
0-99min
Chamber temperature equal
≤ ± 1℃
Source power
1.5KW / AC220V 50Hz
Sterilizing plate
340×200×30 mm (3 pieces)
400×200×30 mm (3 pieces)
Dimension
480×480×384 mm
580×480×384 mm
Package dimension
700×580×500 mm
800×580×500 mm
G. W/N.W
43/40 kg
50/45 kg
