BG-32 Belt Surface Grinding Machine
BG-32 Belt Surface Grinding Machine

BG-32 Belt Surface Grinding Machine

Brand:NANBEI

Model:BG-32

Application:

product details

Product Details:

Model BG-32 Belt surface grinding machine is of new generation design, made according to the international standard and advanced process technique. It adopts sand belt to grind and polish the specimen. The different belts can be changed swiftly. This machine can be used to replace the disc grinder and manual type abrasive paper grinding. It only takes 1-2 minutes to for each belt to finish the operation. For the grinding of spectroscopy specimen, it is very economic to save time, labour and abrasive paper. This machine can be widely used in laboratories, researching institutes and factories.

Technical Specifications

1. Distance between the centers of two rollers: 255mm

2. Equipped with water cooling system

3. Sand belt: 920mm x 100mm (L x W)

4. Rotating speed: 1400 rpm

5. Surface speed: 768 rpm

6. Motor: 550W

7. Power supply: 380V, three phases, 50Hz

8. Dimensions: 600 × 550 × 310 mm
