MP-2 Grinding & Polishing Machine
MP-2 Grinding & Polishing Machine

MP-2 Grinding & Polishing Machine




product details

Product Details:

Model MP-2 Metallography specimen grinding & polishing machine is equipped with double disks, and it can finish grinding or polishing with two different speeds. The rotating speed of left disk (pre-grinding disk) is 450 rpm and right disk (polishing disk) is 600 rpm. With double disks and different grinding and polishing materials, it can realize the process of rough grinding, fine grinding, rough polishing and finishing polishing. This machine features easy operation and economical applying. It is the ideal specimen preparing instrument for using in  factories, scientific research institutes and laboratories of colleges.

Technical Specifications

1. Diameter of grinding disk: Ø230mm, rotating speed 450 rpm ( or customize)

2. Diameter of polishing disk: Ø200mm, rotating speed 600 rpm ( or customize)

3. Power supply: 370W, 220V, 50Hz

4. Dimensions: 72 × 69 × 31 cm

5. Net weight: 45 Kg
