Product description
NB968-C nucleic acid extraction system, based on the automatic extraction method of magnetic bead adsorption and separation, can well overcome the shortcomings of traditional nucleic acid extraction methods and achieve rapid and efficient preparation of 1-32 samples at a time. With corresponding nucleic acid extraction reagents, it can process various sample types such as serum, plasma, whole blood, swabs, amniotic fluid, feces, tissue lavage, tissue, paraffin sections, bacteria, fungi, etc., which is widely used in fields of disease prevention and control, animal quarantine , clinical diagnosis, entry-exit inspection and quarantine, food and drug supervision, forensic medicine, teaching and scientific research.
Features
Air filter module, ultraviolet disinfection module; an external scanner can be connected to automatically identify program information after scanning and run with one-key touch.
| Items | Parameters |
| Processing volume | 30 ～1000μl |
| Sample throughput | 1～32 |
| Residual amount of magnetic beads | ≤1% |
| Heating temperature |
Cracking heating temperature: room temperature～105℃ Elution heating temperature: room temperature～105℃ |
| Shaking mixing | Adjustable multi-mode and multi-speed |
| Reagent type | Magnetic bead reagent |
| Operation interface | Chinese operating system, color LCD screen touch operation |
| Experiment storage | More than 500 groups of programs can be stored |
| Program management | Flexible to create, edit, apply and delete corresponding programs |
| Pollution control | Exhaust filter module, UV disinfection module |
| Power failure protection | When the power supply is restored after an unexpected power failure, you can freely choose whether to continue the experiment |
| Computer interface | USB |
| Network communication | Scalable Ethernet remote control |
| Dimensions | 400mm×420mm×470mm（W×D×H） |
| Weight | 37kg |
| Voltage | AC220V, 50Hz |
| Operating temperature range | 10℃～40℃ |
| Operating humidity range | Less than 80% |
