Introduction:
HD series of instruments are used for detecting thickness of tablet and capsule.
Applicable standard-
Corporate standard(Thickness tester) Q/12XQ0194-2010
Model:HD-1 Features: -
Used for measuring thickness of peak and wall of capsule.
-
High-accuracy test with the most precise, high-quality homemade centigrade meter.
-
Test range (0～5)mm
-
Test accuracy ±0.01mm
-
Type of capsule 00,0,1,2,3,4 type capsule
-
Dimension (200×80×50)mm3
Model:HD-2
Features:
-
Used for measuring thickness of peak and wall of capsule & diameter of tablet and pill.
-
High-accuracy test with the most precise, high-quality homemade centigrade meter.
-
Test range (0～30)mm
-
Test accuracy ±0.01mm
-
Type of capsule 00,0,1,2,3,4 type capsule
-
Range of test tablet 0～30mm
-
Dimension (200×80×50)mm3
Model:HD-3
Features:
-
Used for measuring thickness of peak and wall of capsule.
-
High-accuracy test with the most precise, high-quality homemade centigrade meter.
-
Test range (0～5)mm
-
Test accuracy ±0.01mm
-
Type of capsule 00,0,1,2,3,4 type capsule
-
Dimension (160×60×50)mm3
Model:HD-4
Features:
-
Used for measuring thickness of peak and wall of capsule & diameter of tablet and pill.
-
High-accuracy test with the most precise, high-quality homemade centigrade meter.
-
Test range (0～30)mm
-
Test accuracy ±0.01mm
-
Type of capsule 00,0,1,2,3,4 type capsule
-
Range of test tablet 0～30mm
-
Dimension (160×60×50)mm3
The other models we supply:
