Carbon Dioxide Meter

Product Model: TPJ-26, TPJ-26-I


1 .Compact and handsome volume that can set parameters on the mainframe, also can set the parameters in the computer

2. Large-screen LCD, guiding operational procedures

3. With the exception of automatically recorded, can also be manually record, open and stop

4. A powerful data analysis capabilities, free software upgrades

Model NO

Function difference



Max test range: 2000PPM


Max test range: 5000PPM


Can manually open the switch, set up the date by prompt, manual or automatic mode, if you choose manual mode, press the button each time and the data is recorded. Can record the time and some parameters ( like temperature, moisture, Light, CO2, etc.) . If you choose automatic mode, we should set a good time interval (1-5 hours), the equipment can be set in accordance with good spacing and record data automatically . After the data collection, can press the stop button, you can view historical data on the mainframe, the computer can also be downloaded and automatically demonstrate the form curves and graphics. Software can print and data processing.

If you choose to use the computer open mode, and that all keys will fail to ensure data authenticity and continuity.

Technical paramter:

Record capacity: 1-120000 groups
Measuring range: 0-2000ppm (TPJ-26), 0-5000ppm (TPJ-26-I)
Record time interval: 5 seconds -90 hours continuously adjustable
Sensor communication: RS485                Resolution: 1ppm
Computer Communication: USB1.1            Accuracy: ±50ppm

Power: 5 AA batteries, 9V/2A power source.    Stability: <30ppm/yr
