NB-H-ProA Hotplate Magnetic Stirrer
NB-H-ProA Hotplate Magnetic Stirrer

NB-H-ProA Hotplate Magnetic Stirrer




product details

• Digital control with max. temperature at 340℃,max speed up to 1500rpm.
• Aluminum alloy work plate with flat plane provides fast heating perfermance, and strong compatibility with various heating containers and heating blocks.
• High-resolution LCD display shows actual temperaturesand speed.
• PID controller ensures a precise and steady heating process.
• External temperature control is possible by connecting the temperature sensor(PT 1000) with accuracy at ±0.2°C.
• Brushless DC motor enables more powerful speed control.
• Three heating modes for selected ( fast heating, standard heating and stable heating ).
• Remote control function through RS232 interface provides PC control and data transmission.


Work plate dimensionφ135mm(5inch)
Work plate materialAluminum
Motor typeBrushless DC motor
Heating temperature rangeRoom temp.-340℃, increment 1℃
Temperature display accuracy±0.1℃
Heating power600w
Speed range100-1500rpm resolution±1rpm
Max. stirring quantity[H2O]20L
Speed displayLCD
Temperature displayLCD
Motor rating input18w
Motor rating output10w
Max. magnetic bar[length]80mm
Temperature control accuracy±1°C(<100℃) ±1%(>100℃)
External temperature sensorPT1000 (accuracy ±0.2℃)
Over temperature protection420℃
"Hot" warning50℃
Data connectorRS232
Protection classIP21
Voltage100~120/200-240V 50/60Hz
