GM-1.00 Diaphragm Vacuum Pump
GM-1.00 Diaphragm Vacuum Pump

GM-1.00 Diaphragm Vacuum Pump

Brand:NANBEI

Model:GM-1.00

Application:

product details

 GM-1.00 diaphragm pump


“Nanbei”GM-1.00 diaphragm vacuum pump has features of more advanced design, higher efficiency, longer operating life. It is an all new product engaging in the new and high technology. It is mainly used in medicinal products analysis, tenuously chemical engineering, biochemical pharmacy, food examination, investigating and solving criminal case, etc. It is an ideal product used with the high-accuracy chromatogram apparatus, and it is the essential equipment in the laboratory.

The body of “Nanbei”GM-1.00 diaphragm vacuum pump is made of aluminum alloy through die casting. It is antiseptic, sprayed, agile and beautiful. It has the features of higher antisepsis, wider working range. It can meet requirements of all kinds of working environments.



Technique parameter



Pumping speed:

(L/Min)

60

Pump Head

2

Ultimate Pressure

Vacuum

Pressure

≥0.08Mpa

200mbar

40 Psi

Voltage Rating

230Vac, 50Hz

Pressure

≥ 30 Psi

Noise Level(dB)

<50

Dimensions

(L x B x H)(mm)

300×160×235

Temp of the body(℃)

<55

Motor Power(w)

160

Weight (Kg)

10

Inlet  (mm)

Outlet (mm)

φ6

Φ6

Diaphragm

Valves

NBR

NBR

Working Temp(℃)

7—40

Function

Vacuum & Pressure



diaphragm vacuum pump
