10kN 20kN 50kN 100kN MWW man-made board electronic universal testing machine
10kN 20kN 50kN 100kN MWW man-made board electronic universal testing machine

10kN 20kN 50kN 100kN MWW man-made board electronic universal testing machine

Brand:NANBEI

Model:10kN 20kN 50kN 100kN

Application:

product details

1. Applications and features:

MWW Man-made Board Electronic Universal Testing Machine adopts mechanical load, electronic measurement, digital control and speed regulation, and applies computer real-time control. The machine is could progress various mechanical tests for man-made board and can fit for GB/T17657-1999 man-made and Silk face man-made board physicochemical testing method. The machine is suitable for medium density fiberboard, shaving board, plywood and core-board. It could conduct plane tensile strength, static bending strength, modulus of elasticity, hold screw force, inter bond strength, surface bond strength, bonding strength and shearing of man-made board tests.

2. Main technical parameters:

Series
MWW Man-made Board Electronic Universal Testing Machine
Max. Capacity(KN)
10kN
20kN
50kN
100kN
Grade of testing machine
1 level
Test force range (kN)
0.2~10kN
0.4~20kN
1~50kN
2~100kN
Measurement accuracy
±1%
Displacement accuracy
0.01mm
Test speed range
0.1~200mm/min
0.1~100mm/min
Valid test width
380mm
400mm
Effective tensile space
650mm
650mm

Fixtures
1. Bonding strength measurement and tensile fixtures 1 set
2.modulus of rupture and modulus of elasticity 1 set
3.Hold screw force fixtures 1 set
4.inner bond strength fixtures 1 set
5.Surface bond strength fixtures 1 set
6. glue line Shearing strength fixtures 1 set
Computer configuration
Lenovo computer 1 set
Printer
HP A4 colour ink-jet printer
Software
English version WINDOWSXP software 1 set
Power
1.2kw
1.5kw
Voltage
220V and 380V (Can configured with national standard voltage)
External dimensions(mm)
700×410×1680
760×480×1800
Weight
350kg
500kg


3. Functions
1)Software packages
The computer data processing software is based on WindowsXP operating system platform. It can satisfy different testing materials and complete tensile, compression and bending tests.
Features of the software package:
(1) Measuring the force value, deformation and displacement synchronously.
(2) Test curve real-time display
(3) Can delete arbitrary testing result arbitrarily.
(4) Can zoom and print testing curve. Can select parameter points on the curve (yield point, elastic, etc).
(5) Use VB+SQL language to calculate parameter, it is reliable and convenient.
(6) Can obtain metal materials tensile( pressure) strength, yield strength, δ0.2, disproportional strength, elongation strength etc.

2) Microcomputer system: Use the Lenovo brand microcomputer as host machine to finish the testing setting setup, data acquisition, display and print test results etc(include: main engine, 17 "LCD and large capacity hard disk); equipped with KQL-PowerTest2001 in English and Chinese version which is intelligent test software packages; Can provide standard measurement and judgment of performance parameter for all kinds of material, add up and processing the data; output various requirements of the test report and test format curve.

3) Computed mode: Hand valve operation, and equipped with manual control operation box, contains 6 buttons (rise,fall, upper clamping, bottom clamping, upper loosen, bottom loosen), the operation more convenient, safe and reliable.

4) Safety protection: Equipped with oil cylinder protection system, overload autostop system, overcurrent outostop system and emergency switch protect function.
